What Is an Oxygen Concentrator?
Find out what an oxygen concentrator is, how it functions, the main types available, and how to pick the right one for your needs.
Oxygen concentrators are medical devices that pull oxygen from the air around us and deliver it in a purified form. These machines can be essential for people with breathing difficulties and oxygen-related medical conditions. A concentrator helps reduce breathlessness by supplying oxygen when your lungs are struggling to provide enough naturally.
What Is an Oxygen Concentrator?
Originally, oxygen concentrators were large, heavy systems that required assistance to move. Modern versions are smaller, lighter, and more efficient. Portable oxygen concentrators, also known as POCs, emerged in the early 2000s, with devices like the Inogen One pioneering portability in oxygen therapy. Today, travelers, active adults, and medical patients use portable units for mobility, including on commercial flights.
POCs operate on rechargeable batteries, weighing as little as 3 to 10 pounds depending on the model. They enable users to maintain therapy during errands, travel, or long days outside the home without needing heavy oxygen tanks.
How Do Oxygen Concentrators Work?
This section explains the core mechanism behind oxygen concentrators and how oxygen delivery varies between systems.
Basic Mechanism
An oxygen concentrator draws in room air, filters out nitrogen, and delivers purified oxygen back to the user. This process relies on a technology called Pressure Swing Adsorption, or PSA. PSA uses pressure to trap nitrogen in specialized filter materials so oxygen can pass through.
Inside the device, air is compressed and forced into sieve beds filled with zeolite. Zeolite captures nitrogen, allowing concentrated oxygen to continue through the system. When the pressure drops, the trapped nitrogen is released back into the air, and the system resets for another cycle. This repeated process ensures a continuous supply of medical-grade oxygen.
The primary components inside oxygen concentrators include
• Compressor to pressurize incoming air
• Zeolite-filled sieve beds to separate nitrogen
• Pressure regulator to purge nitrogen and maintain safe flow levels
• Oxygen delivery tubing and interface, typically a nasal cannula
Many portable units come with a protective carry case to prevent damage and simplify everyday transportation.
Oxygen Delivery Methods: Continuous Flow vs Pulse Dose
Oxygen concentrators provide oxygen through two delivery systems: Continuous Flow and Pulse Dose Flow. Your doctor prescribes a specific flow rate that determines how much oxygen you receive.
Continuous Flow
Continuous flow supplies oxygen steadily regardless of breathing patterns, similar to water continuously running from a faucet. Flow is measured in liters per minute.
Pros
• Suitable during sleep
• Ideal for patients who require a constant and reliable oxygen supply
• Shown to reduce mortality in severe COPD when used around the clock
Cons
• Larger and heavier devices
• Higher power consumption
Pulse Dose Flow
Pulse dose systems detect inhalation and deliver oxygen only when you breathe in, like turning on a faucet only when water is needed. Flow is measured in milliliters per breath.
Pros
• More efficient power use
• Smaller, lighter devices suitable for mobility
Cons
• Delivery may be inconsistent for users with shallow or irregular breathing
• Not always ideal for sleep or severe respiratory impairment
Emerging technology is improving pulse detection. Research on enhanced nasal interfaces has shown improved pulse delivery accuracy compared to standard nasal cannulas, although more clinical studies are ongoing.
Types of Oxygen Concentrators
There are two primary categories: portable oxygen concentrators and home oxygen concentrators.
Portable concentrators focus on mobility. They are
• Lightweight
• Battery powered
• Designed for active users
• Primarily pulse-dose devices
Home concentrators prioritize long-term continuous oxygen therapy. They are
• Stationary units
• Powered by wall outlets
• Better suited for patients needing uninterrupted oxygen supply
Key Differences
• Portability: Portable units are small and battery-operated; home units are larger and stay in one place
• Flow capability: Home systems typically provide continuous flow; many portable systems only offer pulse flow
Who Should Use an Oxygen Concentrator?
Oxygen concentrators are prescribed for individuals with chronic respiratory conditions or temporary oxygen needs during certain activities.
Patients with Chronic Respiratory Conditions
People diagnosed with conditions such as
• COPD
• Asthma
• Pulmonary fibrosis
• Lung cancer or other progressive lung diseases
Physicians evaluate medical history, symptoms, and family history before prescribing oxygen therapy. Physical exams and diagnostic tests confirm whether oxygen therapy is required.
Medical Examinations
A common screening method is pulse oximetry, a quick, non-invasive test that clips to a finger, toe, or earlobe. If oxygen saturation consistently falls below 92 percent, further testing is performed. The gold-standard evaluation is an arterial blood gas test, which directly measures oxygen, carbon dioxide, and blood pH. If results fall below 90 percent, oxygen therapy becomes a strong consideration.
Doctors may test oxygen levels during different activities such as walking, sleeping, and exercise to determine full therapy needs.
Situational Use
Some individuals only require oxygen in specific situations, such as
• Exercise
• Travel to high elevations
• Sleep apnea or nighttime hypoxemia
Sleep apnea is typically treated with CPAP first. If oxygen desaturation persists, supplemental oxygen may be recommended following overnight sleep studies and pulse oximetry evaluations.
How to Choose the Right Oxygen Concentrator
Before purchasing a device, three key areas must be reviewed:
What matters most when comparing devices?
What does the patient need for daily living?
What does the physician recommend?
Factors That Matter
Consider the following
• Prescribed oxygen flow rate and settings
• Portability needs and activity level
• Battery life for outdoor use or travel
• FAA approval for air travel
• Brand reliability and warranty support
User Needs
People with high oxygen requirements often need a home concentrator. Those who travel frequently or want to remain active benefit from lightweight portable concentrators.
Consulting Your Doctor
Always talk with a licensed medical provider before starting oxygen therapy. Proper testing and medical review ensure you receive the appropriate flow rate and device type. Brands widely used in clinical settings include Inogen, Philips Respironics, Caire, and ResMed.
Maintenance and Care for Oxygen Concentrators
Consistent maintenance improves device lifespan and ensures reliable therapy.
Routine Cleaning and Filter Replacement
• Clean nasal cannulas and masks regularly to prevent bacteria buildup
• Replace internal and external filters as directed by the manufacturer
• Keep the machine in a dry, dust-free environment and avoid blocked air vents
Safety Guidelines
• Never smoke or use open flames near oxygen equipment
• Keep oxygen tubing away from heat sources
• Use a humidifier if dryness occurs in nasal passages
• Inspect tubing and connections frequently for wear or leaks
Conclusion
Oxygen concentrators are vital tools for many people living with respiratory disease. They provide safe, continuous access to purified oxygen at home, on the go, and during travel. With portable and home units available, and both continuous and pulse-dose delivery systems, your doctor will help determine the right option based on your medical testing and lifestyle. Once selected, proper maintenance ensures your device continues to deliver dependable oxygen support.
If you believe you may benefit from oxygen therapy, consult a qualified medical professional before obtaining a device. A thorough evaluation will determine whether oxygen is necessary and which system is best suited to your needs.
